Sonoline C Professional Handheld fetal doppler fetal heart MSLDSC

More Views

Sonoline C Professional Handheld fetal doppler fetal heart MSLDSC

Be the first to review this product

Pocket Fetal Doppler is a hand-held obstetrical unit, which can be used in hospital,
clinic and home for daily self-check by pregnant woman.
FOB Price: US $ 10-87 / Set|Get Latest Price
MOQ: 1 Set
Supply Ability: 1000 Sets per Month
Port: Guangzhou
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal, Escrow
Contact Suppliper

Pocket Fetal Doppler is a hand-held obstetrical unit, which can be used in hospital,

clinic and home for daily self-check by pregnant woman.The device uses color LCD
of high resolution to display the fetal heartbeat waveform, and figure out the FHR to
help the doctor diagnose in time.It contains components of ultrasonic signal
transmitter and receiver, analog signals processing unit, FHR calculating unit, LCD
display control unit etc. It has 3 work modes: real-time FHR display mode, averaged
FHR display mode, and manual mode .It also has audio output, and can be
connected with earphone or recorder with audio input.

cheap Sonoline C Professional Handheld fetal doppler fetal heart MSLDSC

MSL Sonoline C Professional Handheld fetal doppler fetal heart MSLDSC Main Features



Beautiful shape, portable, easy operation
The probe has bending structure which is easy to operate and can increase the
ease of the pregnant women, embodies the humane care design
Fetal heart rate values, bar graph and heartbeat waveform color screen display
Alarming in red when the fetal heart rate range is out of the normal range
Battery status indicator
The probe can be changeable
Probe inspection
Built-in speaker
Output for headphone
Auto shut off
Two pieces of standard 1.5V alkaline battery available which can work no less than
8 hours

advanced Sonoline C Professional Handheld fetal doppler fetal heart MSLDSC


Best Sonoline C Professional Handheld fetal doppler fetal heart MSLDSC Main performance

Anti-electroshock Type: Internally powered equipment
Anti-electroshock Degree: Type B applied part
Display: 1.77"262K TFT display
FHR Measuring Range: 50BPM ~ 240 BPM (BPM: beat per minute)
Resolution: 1 BPM
Accuracy: ±2 BPM
Power Consumption: < 0.8 W
Voltage: DC 3.0 V
Power Supply: TWO 1.5V(AA size)alkaline battery
Suitable Using Range: Suitable for use after the 12th week of pregnancy
Auto Shut-OFF: After 1 minute no signal, power off automatically

new Sonoline C Professional Handheld fetal doppler fetal heart MSLDSC

Probe:
Nominal Frequency: 2.0 MHz
Working Frequency: 2.0 MHz ± 10%
Ultrasound Output Power: P < 10 mW
Ultrasonic Output Intensity: Isata < 5mW/cm2
Negative Peak Sound Pressure : p_ < 0.5 MPa
Working Mode: Continuous wave doppler
Effective Radiating Area of Transducer: 157 mm2 ± 15%


Physical Characteristic
Dimension: (L) 135 mm × (W) 92 mm × (H ) 29 mmWeight: About 245 g (including
batteries)

Qualification
Passed CE
Anti-electroshock Type: Internally powered equipment
Anti-electroshock Degree: Type B applied part
Display: 1.77"262K TFT display
FHR Measuring Range: 50BPM ~ 240 BPM (BPM: beat per minute)
Resolution: 1 BPM
Accuracy: ±2 BPM
Power Consumption: < 0.8 W
Voltage: DC 3.0 V
Power Supply: TWO 1.5V(AA size)alkaline battery
Suitable Using Range: Suitable for use after the 12th week of pregnancy
Auto Shut-OFF: After 1 minute no signal, power off automatically

Since the beginning establishment of Guangzhou Medsinglong Medical Equipment Co., Ltd, we have been working in the medical field applications and product innovation. After several years of development, now our products are exported to over 110 countries, the United States, Germany, France, Australia, Turkey, Saudi Arabia, Malaysia and Nigeria included. Furthmore, our company has passed the ISO13485 international quality management system certification, CE certification and RoHS certification.

Nowadays, we sell three series ultrasound products including Human ultrasound, Vet animals ultrasound and Ophthalmology ultrasound. Wide ranges of ultrasound such as Notebook B ultrasound, Handheld, 4D ultrasound and other special type of ultrasound products, of which under unique proprietary core technology in the international leading level.

As a developing Medical Devices team, we pursue the goal of "More healthier in technology", and adhere to the idea of "Innovating technology, living healthier". Therefore, we have made a contribution for human health in committing and promoting advanced technologies products for many years.

We are looking forward to cooperating you from differ medical fields around the world, and we firmly believe that we will make you satisfied with our high quality products and good serves.









Welcome to ultrasoundmsl.com, If you have any demand in Ultrasound machine. Please feel free to contact sales@ultrasoundmsl.com

MSL Medical cooperate with DHL, FEDEX, UPS, EMS, TNT, etc. International shipping company, make your goods arrive destination safely and quickly.
